Cable Management Systems
Domaille Engineering Fiber Optic Equipment has designed many different cable management versions including a modular Cable Management System designed to easily handle most cable types. The system will improve polishing results by minimizing the effects of cable weight and distortion on the polishing fixture.
Domaille Engineering has also designed special cable management for MPO and MTRJ cables that improve the yields on these difficult-to-produce cables.

Cable management options

Richen Code	Domaille Part Number	Description	Image
81045700	CM15120-1	20-Port with Flat/Ribbon Clamps Holds up to Ø3.6mm Flat Cable
81045800	CM15120-2	20-Port with Rounds Cable Clamps Holds up to Ø3.6mm Round Cable
81045900	CM15120-3	20-Port with Ribbon Jacket Clamps Holds up to Ø3.6mm Cable
81046000	CM15120-4	20-Port w/16 Fiber Ribbon Jacket Clamps Holds Ø3.6mm Cable
81029700	CM15150	12-Port Round Cable Management Holds Ø3.6mm -Ø9.5mm Cable [Available in stiffer spring - CM15150S]
81046100	CM15158	Round Cable Management Riser [Available in stiffer spring - CM15158S]
81046200	CM15152	6- Port Round Cable Management Holds Ø3.6mm -Ø9.5mm Cable
81037400	CM15170	16- Port Cable Management Holds up to Ø4.5mm Cable [Replaceable Foam Insert PN CM10172]
98000500	MTEZ52000	Halo MTEZ Fixture Holds Ø0-6mm Cable
81047000	CM15002	Flex Cable Management, SC-WH PF Designed for PFA-SCW83P-16
81047100	CM15003	Loc-Line Cable Management, SC-WH PF Designed for PFA-SCW83P-16
81046500	CM15130	24 Port, 2 Tier, Holds Ribbon Cable, Post Mount
81046600	CM15131	24 Port, 2 Tier, Holds Ø1.2-4mm Cable, Post Mount
81046700	CM15135	24 Port, 2 Tier, Holds Ribbon Cable, Flange Mount
81046800	CM15136	24 Port, 2 Tier, Holds Ø1.2-4mm Cable, Flange Mount
81046900	CM15200	12 Port, 2 Tier, Holds Ø2-6.2mm Cable, Post Mount
81047000	CM15202	12 Port, Holds Ø3.6-9.5mm Cable, Post Mount
81047100	CM15203	12 Port, Holds Ø3.6-9.5mm Cable, Flange Mount
81047200	CM15205	12 Port, 2 Tier, Holds Ø2-4mm Cable, Post Mount
81047300	CM15199	Height Customizable CM Kit includes: CM10100 Mounting Collar CM10101 2" Riser Shafts (x4) CM10102 3" Riser Shafts (x4) CM10160 4" Riser Shaft (x4) CM12130 Offset Pull Handles, 2", SS + Screws/Wrenches *Recommended for purchase with one of: CM15220, CM15221, CM15222, CM15223, CM15224, CM15225 or CM15226
81047400	CM15220	12 Port, Holds Ø3.6-9.5mm Cable, Half Plate Pair *Recommended for Stiff Cables
81047500	CM15221	12 Port, Holds Ribbon Cable, Half Plate Pair
81047600	CM15222	12 Port, Holds Ø2-6.2mm Cable, Half Plate Pair
81047700	CM15223	20 Port, Holds Ribbon Cable, Half Plate Pair
81047800	CM15224	20 Port, Holds Ø1.2-4mm Cable, Half Plate Pair
81047900	CM15225	24 Port, Holds Ribbon Cable, Half Plate Pair
81048000	CM15226	24 Port, Holds Ø1.2-4mm Cable, Half Plate Pair
