Tempo 567XL SILICON FIBER OPTIC POWER METER
Model Number:567XLBrands:TempoRichen Code:57000200
The Special Launch Condition Sources and Optical Power Meter XL fiberTOOLS™ are designed for the professional to perform installation and maintenance measurements on both Plastic & Glass fiber optic networks. The instrument family consists of Stabilized Light Sources with stringent Launch Conditions and a large area detector OPM for the Avionics, Defense Industries and Research Laboratories

The Special Launch Condition Sources and Optical Power Meter XL fiberTOOLS™ are designed for the professional to perform installation and maintenance measurements on both Plastic & Glass fiber optic networks.
The instrument family consists of Stabilized Light Sources with stringent Launch Conditions and a large area detector OPM for the Avionics, Defense Industries and Research Laboratories


Features

• Easy to use - three buttons control all functions
• Long battery life
• Loss measurements in (dB); power measurements in (dBm)
• 0.01dB measurement resolution
• Snap on connector interface adapts to FC, SC and ST connectors
• Contact Tempo for other available adapters
• User selectable auto shut-of
• Rugged and splash-proof
• Economically priced

规格参数1

Richen Code

Model Number

Describe


10007900

T1026

1.25 mm quick connect universal adapter (LC, MU, etc.)

1

10008700

T1025

2.5 mm SOC quick connect adapter

2

10009800

T1020

FC

3

10008800

T10LC

LC

4

10007800

T1062

SC

5

57002500

T1087

SMA 905/906

6

10008100

T1030

ST

7

10008500

T10ZP

Versatile Link - V/Z PIN

8

57002700

T1030-POF

ST

9
