Richen Code

Part Number

Part Number （Used）

Describe

Product images

83012400

30-AD-000732

3DS-ADAPT-APC-LC

Adapter, 1.25mm LC, (with Dscope PM: used for calibration only）

83015600

30-AD-000734

3DS-ADAPT-APC-MU

MU/APC plate

83000114

30-AD-000735

3DS_ADAPT_APC_E2000

E2000/  APC plate

83000113

30-AD-000739

3DS_ADAPT_APC_SC

Adapter, 2.50mm SC (with D Scope PM: can be used for measurement + is required for calibration with the 2.50mm calibration stub)

83000111

30-AD-000737

3DS_ADAPT_APC_FCN

FC/APC Narrow adapter

83000112

30-AD-000738

3DS_ADAPT_APC_FCW

FC/APC Wide adapter

83004300

30-MT-000938

DPLC-KK-V2-CONN-MOUNT-SA

Holder (new design) for the 1.25 and /or 2.5mm chucks (V Groove type) for Connector module Mount, for 1.25mm or 2.50mm Holder for Patchcord Concentricity Measurement (new model, V Groove), Sapphire hardstop

83013900

30-MT-001956

Mount, specific for SMA / 3.17mm Holder for Patchcord Concentricity Measurement (new model, V Groove), without hardstop NB: required with SMA holder, for SMA connectors Compatibility with: KK-Connector-V2: required with SMA holder, for SMA connectors

83000202

30-HL-000719

DPLC-42-1.25-V2

Holder 1.25mm for Patchcord Concentricity Measurement (sleeve-type)

83000201

30-HL-000720

DPLC-42-2.5-V2

Holder 2.50mm for Patchcord Concentricity Measurement (sleeve-type)

83000204

30-HL-000721

DPLC-42-2.5-V2-E2000

Holder 2.50mm E2000 PatchcordConcentricity Measurement with variable Internal Diameter,designed for E2000 pigtail (sleeve-type)

83000203

30-HL-000722

DPLC-42-SMA

Holder 3.17mm SMA Patchcord Concentricity Measurement (sleeve-type)

83000205

30-HL-000723

DPLC-KK-V2-2.5

Holder 2.50mm for Patchcord Concentricity Measurement (V- Groove-type) (not compatible with E2000 connectors). NB: If this part is to be used on a Koncentrik-V2 unit, this unit must be equipped with amount (part # 30-MT-000938).

83000206

30-HL-000724

DPLC-KK-V2-1.25

Holder 1.25mm for Patchcord ConcentricityMeasurement (V- Groove-type) NB: If this part is to be used on a Koncentrik-V2 unit, this unit must be equipped with amount (part # 30-MT-000938).

83011900

30-HL-000725

DPLC-KK-V2-SMA

Holder 3.17mm SMA for Patchcord Concentricity Measurement (V-Groove-type) NOTE: If this part is to be used on a Koncentrik-V2 unit, this unit must be equipped with a specific mount (part # 30-MT-001956). Compatibility with: KK-Connector-V2 3Dscope-V1 Former reference: DPLC-KK-V2-SMA

83011800

30-HL-000726

DPLC-KK-V2-2

Holder 2.00mm for Patchcord Concentricity Measurement (V-Groove-type) Note: If this part is to be used on a Koncentrik-V2 unit, this unit must be equipped with a mount (part # 30-MT-000938). Compatibility with: KK-Connector-V2

80052900

30-HL-000727

DPLC-KK-V2-1,6

Chuck 1.6 mm for Patchcord Concentricity Measurement (new model, V Groove)

30-HL-000923

Holder 2.50mm, for Patchcord Concentricity Measurement (V- Groove-type), specific for E2000

incl. design modifications of November 2017.

30-HL-000924

Holder 2.50mm - short - for Patchcord Concentricity Measurement (V- Groove-type), specific

(minimum ferrule length 3.50mm)

30-HL-002866

OPP191

Holder 1.25mm DUPLEX for Patchcord Concentricity Measurement
