Proton™ consistently achieves Telcordia compliant, singlemode UPC and APC finishes in a handheld and battery operated package. Proton™ incorporates the same Independent Suspension (IS) and optically aligned workholder design found in Krell’s Scepter™ Mass Production Polishing Systems. Proton™ can polish connectors sideways and at most orientations, permitting access to cabling in the tight confines of datacom wire closets, LAN cross-connects, and CATV fiber nodes. Proton™’s portability lends itself to various military and aerospace applications and networks in which field-deployed optical connectors are terminated or require servicing and repair. Mil-spec components and termini including M29504, LuxCis, ARINC 801, ELIO, MC5, RSC, etc.

Production performance is now available in field environments in the form of Proton™. Though portable and battery operated, Proton™ consistently achieves singlemode UPC and APC finishes. Proton™ incorporates the same Independent Suspension (IS) and optically aligned workholder design found in Krell’s mass production Scepter™ Polishing System.

Proton™ workholders feature Independent Suspension (IS) for controlled pressure and uniform contact with the polishing surface. The workholder is also optically aligned. for optimal polish

VERSATILE
Proton™ has been conceived for true hand-held operation. Connectors can be loaded, polishing pressure set and films changed-out without the need of a table, workbench or external support. Proton™ can polish connectors sideways and at most orientations, permitting access to cabling in the tight confines of wire closets, cross-connects and fiber nodes.

PORTABLE
This unique design makes Proton™ the ideal choice for all field networks such as Fiber to the Home/Premise (FTTX), shipboard/aircraft, CATV and LAN. Whether the application is a new installation, connector repair or even R&D efforts, Proton™ provides the required performance.

Features
• SINGLEMODE PERFORMANCE
• COMPLETE HAND-HELD OPERATION
• INDEPENDENT SUSPENSION WORKHOLDERS
• SUPPORTS ALL INDUSTRY STANDARD AND MIL-SPEC CONNECTORS/TERMINI
• TELCORDIA COMPLIANT

• Krell Proton™ FTTX Proton Video Manual

• Krell Proton™ FTTX Manual Operation Video

Q: Can this recover damaged connectors to Telcordia specifications?

A: Proton's actively aligned workholders are designed to achieve Telcordia geometries on ferrule endfaces.

Q: Can this polisher be used in a lab?

A: Yes. We offer a stand for benchtop/table operation.

Q: What is included with the purchase of this unit? Does it polish SC, LC, FC both UPC and APC? Thanks.

A: Workholder fixtures (ie. for SC-UPC, SC-APC, FC-UPC, FC-APC, etc) are purchased as needed with the base Proton polisher. Please forward your specific connector requirements to sales@krelltech.com and we will generate a quotation for your application.

Q: Can Proton polish two connectors?

A: Since Proton is designed for repair, only one connector can be polished at a time.

Q: Can Proton be used to polish newly terminated connectors?

A: Proton is designed to be used in the termination process, as well as repairing damaged connectors and termini.

Q: Does the Proton have a built-in polishing timer?

A: Yes, the timer allows for adjustable cycles for polishing routines.

Q: Is the proton battery powered?

A: It is indeed!

Q: Is the Proton portable?

A: Yes!

Q: Can I purchase a stand for the Proton Field Polisher?

A: Yes, a stand is available for tabletop operation.

Q: Is Proton left, or right handed?

A: Proton can be operated by either hand.

Q: Does Proton only repair damaged connector?

A: Proton can repaired damaged connectors and also polish newly terminated connectors.

Q: Can Proton polish these attached connectors?

A: Yes, these and all UPC style termini and connectors.

Q: Can Proton run on AC power?

A: Yes, both AC power and standard 9 volt battery operation.
