Richen Code

Cable Management P/N

Cable O.D

Method

Corresponding Polishing Holder P/N

External Image

80144300

IPC-P-CMH-SCA18

2 to 7mm

Clip-clamp

PH55-CP8C-18

---

PH55-CP8A-18

80199400

IPC-P-CMH-SCA18-W

2 to 7mm

Double Clip-clamp

PH55-CP8C-18

---

PH55-CP8A-18

---

NOTE 1) For OptiTap use, this is the suitable type. 2) Also use of the Removable housing is necessary. 3) Polishing shall be done before crimp

80140000

IPC-P-CMH-LC32DHP

2 to 7mm

Clip-clamp

PH55-PL-32DHP

---

PH55-PL-32DFX

---

(Single and Uniboot use)

80199500

IPC-P-CMH-LC24

2 to 7mm

Clip-clamp

PH55-PL-24

---

 (Single boot use)

80199600

IPC-P-CMH-SCA32

2 to 4mm

Holding groove

PH55-CP8C-32

---

PH55-CP8A-32

80199700

IPC-P-CMH-SCA32-D5

5 to 6 mm

Holding groove

PH55-CP8C-32

---

PH55-CP8A-32

80199800

IPC-P-CMH-LC48DHP-U

2 to 3mm

Holding groove

PH55-PL-48DHP (Uniboot use)

80199900

IPC-P-CMH-LC48HP-U

2 to 3mm

 Holding groove

PH55-PL-48 (Uniboot use)

80200000

IPC-P-CMH-LC48

2 to 3mm

Holding groove

PH55-PL-48 (Single boot use)

80200100

IPC-P-CMH-LA48

 2 to 3mm

 Holding groove

PH55-PL8A-48

---

PH55-PL8A-48HP

80151000

IPC-P-CMH-LCA32-U

2 to 7mm

Clip-clamp

PH55-PL8A-32DHP-POR

---

PH55-PL8A-32DFX-POR *1 (Uniboot use *2)

---

NOTE  *1: Use with SFP-560A only   * 2: Uniboot must be SG

80200200

FXH-P-CMH-LC32-U

2 to 4mm

Clip-clamp

PH55-PL-32DFX  *1 (Uniboot use)

---

NOTE *1: Use with SFP-560A only

80200300

FXH-P-CMH-LC48-U

2 to 4mm

Clip-clamp

PH55-PL-48DFX *1 (Uniboot use)

---

NOTE *1: Use with SFP-560A only

80153900

MT-P-CMH56-B

4 to 8mm

Screw lock

NOTE: USE WITH SFP-560A ONLY

---

PH55-MT-12S1

---

PH55-MT8A-12S1

---

PH55-MT-24S1

---

PH55-MT8A-24S1

---

PH55-MT-12SQ1-B

---

PH55-MT-24SQ1-B

---

PH55-MT8A-12SQ1-B

---

PH55-MT8A-24SQ1-B

80159000

MT-P-CMH56-D (STANDARD)

2 to 4mm

Spring lock

NOTE: USE WITH SFP-560A ONLY

---

PH55-MT-12S1

---

PH55-MT8A-12S1

---

PH55-MT-24S1

---

PH55-MT8A-24S1

---

PH55-MT-12SQ1-B

---

PH55-MT-24SQ1-B

---

PH55-MT8A-12SQ1-B

---

PH55-MT8A-24SQ1-B

80178600

MT-P-CMH56-E

5 to 13mm

Screw lock

NOTE: USE WITH SFP-560A ONLY

PH55-MT-12S1

PH55-MT8A-12S1

PH55-MT-24S1

PH55-MT8A-24S1

PH55-MT-12SQ1-B

PH55-MT-24SQ1-B

PH55-MT8A-12SQ1-B

PH55-MT8A-24SQ1-B

(12 cables only)
